Production of pellet fireplaces and boilers
Pellet fireplaces with air ducts
SUN 32V
SUN 32V
Pellet fireplace with air jacket and air ducts - power 32 kW.
Heated volume - 650 cubic meters
Pipes for air ducts - 2 pcs. F 130mm
Air flow rate through the air ducts - 400 m3/h
Air flow calorific part - 600 m3/h
Automatic microprocessor control
Operating voltage - 12V DC
Automatic ignition
Ceramic glass
Automatic cleaning
Built-in drawer for ash contents
Weekly Programmer
Optical sensor
Warranty-2 years
Nominal power kw 32.00
Minimum power kW 8.00
Fuel consumption at full power kg/hour 6.60
Fuel consumption in sustain mode kg/hour 1.65
Outlet gas temperature C 160.00
Efficiency/Efficiency/ % 89.00
Chimney opening mm 130.00
Air flow rate m³/h 400.00
Temperature of exhaust gas ducts C 115.00
Flow calorific part m³/h 600.00
Heated volume m³ 750.00
Dimensions
Width mm 625.00
Depth mm 660.00
Height mm 1250.00
Power consumption during operation W 12.00
Power consumption at ignition W 120.00
Ignition time minutes 1.00
Pellet hopper volume kg 25.00
Weight kg 240.00
Price: BGN 3450
SUN 16
SUN 16 pellet fireplace with air jacket and air ducts - power 16 kW.
Heated volume - 340 cubic meters
Pipes for air ducts - 2 pcs. F 100mm
Flow rate 650 cubic meters
Automatic microprocessor control
Operating voltage - 12V DC
Automatic ignition
Ceramic glass
Automatic cleaning
Built-in drawer for ash contents
Warranty-2 years
Price: BGN 2,800
Nominal power kw 16
Minimum power kW 3
Fuel consumption at full power kg/hour 2.8
Fuel consumption in maintenance mode kg/hour 0.75
Outlet gas temperature C 130
Temperature of exhaust gas ducts C 115
Air flow rate m³/h 300
Efficiency/Efficiency/ % 91
Chimney opening mm 100
Type of fuel - pellets f6mm
Heated volume m³ 300
Dimensions
Width mm 509
Depth mm 600
Height mm 1020
Pellet hopper volume kg 22
Weight kg 160
SUN 12
SUN 12 pellet fireplace with air jacket and air ducts - power 12 kW.
Heated volume - 300 cubic meters
Pipes for air ducts - 2 pcs. F 100mm
Flow rate 500 cubic meters
Automatic microprocessor control
Operating voltage - 12V DC
Automatic ignition
Ceramic glass
Automatic cleaning
Built-in drawer for ash contents
Warranty-2 years
Price: BGN 2,700
Nominal power kw 12
Minimum power kW 3
Fuel consumption at full power kg/hour 2.8
Fuel consumption in maintenance mode kg/hour 0.75
Outlet gas temperature C 130
Temperature of exhaust gas ducts C 115
Efficiency/Efficiency/ % 91
Chimney opening mm 100
Type of fuel - pellets f6mm
Heated volume m³ 300
Dimensions
Width mm 509
Depth mm 600
Height mm 1020
Pellet hopper volume kg 22
Weight kg 145
FOGO 16
FOGO 16 pellet fireplace with air jacket and air ducts - power 16 kW.
Heated volume - 340 cubic meters
Pipes for air ducts - 2 pcs. F 100mm
Flow rate 650 cubic meters
Automatic microprocessor control
Operating voltage - 12V DC
Automatic ignition
Ceramic glass
Automatic cleaning
Built-in drawer for ash contents
Warranty-2 years
Price: BGN 3,000
Nominal power kw 16
Minimum power kW 3
Fuel consumption at full power kg/hour 2.8
Fuel consumption in maintenance mode kg/hour 0.75
Outlet gas temperature C 130
Temperature of exhaust gas ducts C 115
Air flow rate m³/h 300
Efficiency/Efficiency/ % 91
Chimney opening mm 100
Type of fuel - pellets f6mm
Heated volume m³ 300
Dimensions
Width 880 mm
Depth 410 mm
Height 1060 mm
Pellet hopper volume kg 22
Weight kg 160
FOGO 12
FOGO 12 -
pellet fireplace with air jacket and air ducts - power 12 kW.
Heated volume - 300 cubic meters
Pipes for air ducts - 2 pcs. F 100mm
Flow rate 500 cubic meters
Automatic microprocessor control
Operating voltage - 12V DC
Automatic ignition
Ceramic glass
Automatic cleaning
Built-in drawer for ash contents
Warranty-2 years
Price: BGN 2,800
Номинална мощност _cc781905-5cde- 3194-bb3b-136bad5cf58d_ kw12.00
Минимална мощност _cc781905-5cde- 3194-bb3b-136bad5cf58d_ kW2.40
Fuel consumption at full power kg/hour 2.15
Fuel consumption in maintenance mode kg/hour 0.57
Exhaust gas temperature , C
Efficiency/Efficiency/%89.00
Chimney opening mm 100.00
Flow heater m³/h _cc781905-5cde-3194-50d-6bb35b,
Flow air ducts m³/h_cc781905-5cde-3194-6bb35b ,
Температура изх газове въздуховоди 115C _cc781905- 5cde-3194-bb3b-136bad5cf58d_ _cc781905-5cde-3194-bb3b- 136bad5cf58d_
Heated volume m³240.00
Dimensions
Широчина mm 800
Depth mm
Височина mm _cc781905-5cde-3194 -bb3b-136bad5cf58d_880
Energy consumption during operation W12
Energy consumption on ignition W120
Ignition Time Min.
Pellet hopper volume kg15
Weight _cc781905-5cde-3194-80d_kg
KAS 30V
KAS 30V - pellet boiler with air jacket and air ducts - power 30 kW.
Heated volume - 600 cubic meters
Pipes for air ducts - 2 pcs. F 130mm
Air flow rate through the air ducts - 800 m3/h
Air flow calorific part – 250 m3/h
Automatic microprocessor control
Operating voltage - 12V DC
Automatic ignition
Ceramic glass
Automatic cleaning
Built-in drawer for ash contents
Weekly Programmer
Optical sensor
Warranty-2 years
Price: BGN 3450
Nominal power kw 30
Minimum power kW 9
Fuel consumption at full power kg/hour 4.6
Fuel consumption in maintenance mode kg/hour 1.4
Outlet gas temperature C 160
Ефективност/КПД/ % 89
Отвор на димохода mm _cc781905- 5cde-3194-bb3b-136bad5cf58d_ 130
Дебит въздуховоди м³/ч _cc781905 -5cde-3194-bb3b-136bad5cf58d_ 800
Temperature exhaust gases air ducts C 115
Дебит калориферна част м³/ h 250
Отопляем обем _cc781905-5cde -3194-bb3b-136bad5cf58d_ м³ _cc781905-5cde-3194-bb3b- 136bad5cf58d_ 600
Габаритни размери _cc781905-5cde -3194-bb3b-136bad5cf58d_
Широчина mm _cc781905-5cde -3194-bb3b-136bad5cf58d_ 540
Дълбочина mm _cc781905-5cde- 3194-bb3b-136bad5cf58d_ 460
Височина mm _cc781905-5cde -3194-bb3b-136bad5cf58d_ 1200
Разход на ел.енергия при работа _cc781905-5cde-3194-bb3b -136bad5cf58d_W 30
Pellet hopper volume kg 40
Weight kg 240
